Introduction: This article explains how to connect aerial panoramic images with Realsee 3D tours, providing users with a more comprehensive and immersive spatial exprience.

Step 1: Capture an Aerial Panorama

https://global-public.realsee-cdn.com/release/pagepress/adYTMDlh/uploads/c66aaacd-58f5-4239-b27f-407fa400cf33.png

Step 2: Capture the Realsee 3D tours associated with the panoramic image

Step 3: Link the aerial panoramic image with the Realsee 3D tours

Method 1: You can add a Pano label in the Realsee 3D tours.Go to the Realsee Console, click on the corresponding project to Edit, then navigate to Hotspot and select Pano Label.

https://global-public.realsee-cdn.com/release/pagepress/CZiRZYSG/uploads/4e9442fc-c64b-48f8-b58c-97e28f532ad0.png

Place the cursor at the location where you want to add the Pano label, then click the plus sign on the right to upload the panoramic image. Enter a name and click Save.

https://global-public.realsee-cdn.com/release/pagepress/zWIzkAgq/uploads/c0d31574-ba11-4c8f-9ce4-307a98edb1f2.png

Method 2: You can create a separate Realsee 3D tour from the aerial panoramic image and link it to other ground-level Realsee 3D tours.

First, use 'Pano to 3D' to upload the aerial panoramic image and generate an aerial Realsee 3D tour. https://realsee.ai/GjVVpAbK You can see that this tour is generated from the aerial panoramic image mentioned above.

Then, add a 'Space Label' at https://realsee.ai/GjVVpAbK to link to other Realsee 3D tours. Go to the Realsee Console, click on the corresponding project to Edit, then navigate to Hotspot and select Space.

https://global-public.realsee-cdn.com/release/pagepress/wyXIXKXr/uploads/b1653eb0-c17d-4ff5-bd1b-7e89644a2c58.png

On the right side, fill in the details of the 3D tour you want to link, including the title for the navigation arrow and the title of the 3D tour to associate (once entered, existing corresponding 3D tours will be recognized, and you can simply select one). After selection, a preview of the chosen 3D tour will appear, allowing you to click and adjust the initial view. Once all information is completed, click Save.

https://global-public.realsee-cdn.com/release/pagepress/VnYZGnAv/uploads/878ab14b-262e-42aa-85cf-1ce794db4473.png

You can link multiple 3D tours, and all associated 3D tours will be visible in the 'Label List'.

https://global-public.realsee-cdn.com/release/pagepress/OmGkqxfE/uploads/9f72be99-073b-4333-8ff0-f5697bed50a9.png

After linking the 3D tours, the effect is as follows: You can click the two arrows to enter the corresponding ground-level 3D tour spaces for browsing. https://realsee.ai/EOxxbze2

https://global-public.realsee-cdn.com/release/pagepress/jahflcuX/uploads/9c5cbb0a-3fda-4f4b-a212-b4bf0354de48.png
